150L 200L 280L 400L 500L Horizontal Cylindrical Pressure Steam
High Pressure Heat Steam Aging Test Chamber is a new type of
electromechanical integration equipment. The mechanical body is a
pressure vessel, it is strictly designed and manufactured according
to GB150-1998. All the points which directly contact with
sterilized item, are made by high quality stainless steel. Safe
and pollution-free, short sterilizing time, easy operation,
powerful function and reliable.
High Pressure Heat Steam Aging Test Chamber is suitable for
hospital supply room, operating room,
pharmaceutical factory and scientific research department, etc.
1. The sterilization process is automatically controlled, without
supervision and easy to apply.
2. With drying function to achieve the drying effect of sterilized
3. With over-temperature and over-pressure automatic protection
4. Safety interlock device: when the door is not closed tightly
good and steam cannot enter the inner main body and alarm, and when
the pressure inside the sterilization room is greater than
0.027MPa, the door is interlocked and cannot open the door.
5. Overpressure Protection: The safety valve will automatically
release pressure when the pressure exceeds the working pressure.
6. Low water level protection device: The water cannot be started
until the high water level is reached, and it is protected by
automatic power failure when the low water level is short of water.
7. Over-current protection: when the current is overloaded, the
power circuit breaker will automatically cut off the power.
8. Sterilization chamber is made of high quality stainless steel.
|105℃ - 134℃|
|Time of Drying||0-60 min|
|Power||9KW/380V 50Hz||9KW/380V 50Hz||12KW/380V 50Hz||18KW/380V 50Hz||18KW/380V 50Hz|
|G.W/N.W||320/240 KG||350/260 KG||465/365 KG||530/520 KG||580/470 KG|
