253.7nm T6 UV Sterilizing Lamp Straight Pipe Air Conditioner Purifiers

Categories UVC Disinfection Lamp
Brand Name: UV,Yoway
Model Number: G24T6L
Certification: CE ROHS
Place of Origin: Zhejiang,China
MOQ: 10
Price: 10
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100000 pcs per month
Delivery Time: 5 days
Packaging Details: paper packing or as required
Name: 8w T6 UVC light for air conditioner air purifiers
Material: 99% Quartz for air conditioner air purifiers
Type: double sides , straight for air conditioner air purifiers
Function: bacteria disinfection for air conditioner air purifiers
Working Hours: 8000-12000 hours
Wave Length: 254nm 253.7nm for air conditioner air purifiers
  • Product Details
  • Company Profile

253.7nm T6 UV Sterilizing Lamp Straight Pipe Air Conditioner Purifiers

straight UVC pipe T6 sterilizing UV lamp for air conditioner air purifiers
Application in surface sterilization, UV surface sterilization device is widely used in food, electronics, semiconductor, liquid crystal display, plasma TV, crystal vibrator, precision device, chemical industry, medicine, health care, biology, beverage, agriculture and other fields. The UV light source irradiates the surface of food, materials, etc., and has a fast, efficient and pollution-free sterilization effect, thereby maintaining the high quality of the product. Compared with traditional sterilization methods, surface sterilization has the characteristics of fast sterilization speed, continuous processing and batch processing, simple operation, environmental protection and no secondary pollution .
Garranty time: 12 months Garranty policy: any bad uvc lamp, sent a new one for replacement.
How to use:
According to the regulations of the third edition of the ""Disinfection Technical Specifications"" issued by the Ministry of Health, Volume 2 (Disinfection Specifications), the installation quantity of indoor suspended ultraviolet disinfection lamps is not less than 1.5W per cubic meter on average, and requires uniform distribution and hoisting height distance. The ground is 1.8 ~ 2.2m, so that the human breathing zone is in the effective irradiation range. Continuous irradiation is not less than 30min, the radiation intensity of ultraviolet rays is inversely proportional to the radiation distance, and the suspension is too high, which will affect the sterilization effect. If the surface of the object is sterilized, the distance between the lamp tube and the irradiated surface should be 1m, and the sterilization is effective. The thickness of the water layer used for drinking water disinfection is less than 2 cm. During disinfection, the ambient temperature is controlled at 20°C to 40°C and the humidity is 40% to 60%. Too high or too low temperature will affect the disinfection effect, and the disinfection time can be appropriately extended. Relative humidity When it is greater than 80%, the irradiation time is also appropriately extended.

DOUBLE ENDED UVC LAMPS T6 SERIES
Model nowattage(W)current(mA)voltage(v)life span (h)UVC LIGHT intensity 100cm distance (μw/cm2)
diamemter mmlength mmOzone
G10T6L19(T6)437yes/no1530059-71800044
G24T6L19(T6)589yes/no2032071-91800075
G36T6L19(T6)894yes/no30320105-125800090
G48T6L19(T6)1199yes/no40330110-1308000110

Lamp adapters

There are four : Plastic , Ceramic, Aluminium (blue and silver) lamp adapters for your choice
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 6
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 7
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 8
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 9
Detailed Images

The eight core strengths

1.Core filament electronic power processing technology.
2.Use the best quality raw materials----Glass tube UV transmittance>93%.
3.Unique inner coating film and outer coating film technology.
4.Solid mercury----Homemade special mercury fixation to improve light efficiency.
5.Unique patented rapid leak detection technology
6.Unique wick anti-vibration patented technology .
7.The most advanced automated processing equiment in China. 8.Cost advantage and perfect pre-sales and after-sales service.
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 10
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 11
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 12
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 13
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 14
1.Top quality quartz tube 2.>93% ultraviolet light transmittance 3. High temperature resistance 4. Corrosion resistance 4. Patented anti-fouling technology for the outer coating film of the lamp or quartz sleeve to ensure that the surface of the lamp
is not affected by external environmental pollution.
1.High quality adapter
2.Completely connection
3.Stable and reliable
4.High effeciency
1.Unique inner coating and outer coating technology 2. The internal coating technology ensures that the maximum illuminance attenuation of the ultraviolet lamp during the life of the tube does not exceed 15% Uniform and dense demoulding 2. After 600 degrees high temperature baking, it still maintains continuous density 3. Three layers of protection
CORE TECH
UNIQUE "LAMP HEART TECHNOLOGY"
UV Light & Electricity uses the core filament, electronic powder processing technology, and electronic powder decomposition technology. The filament electronic powder is the "heart of the lamp tube", with strong resistance to bombardment, with up to 10,000 switching times, ensuring the long life of the lamp. 1. The particle size is normally distributed, and the adhesion ability is strong 2. High Ba content, high emission density, strong high temperature resistance 3. The content of Ca is appropriately increased, and the bombardment resistance is stronger 4. Add rare earth oxides to extend the service life
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 15
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 16
How does UV light affect bacteria?
Microorganisms are simple organic structures that can easily absorb UV-C wavelengths, causing
photodissociation (destruction). Microbial DNA (deoxyribonucleic acid) is first adversely affected due to its weaker molecular
bonds. Within a hundredth of a second, it suffered irreparable damage. The subsequent loss of genetic instructions can cause the
cell to die and/or fail to replicate, making it harmless. Continuous exposure will cause uninterrupted degradation, such as the
sun, which will only be significantly faster.
Does UV-C lamp produce ozone?
No, but UVC does provide exceptional air conditioning, just like the sun is outdoors. The UVC fixture
is an air conditioning component in addition to other system components. These components include filters, coils, heating cores,
fans, dampers, humidifiers, etc. All of these components are designed to provide specific functions for treating the air in the
occupied space.
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 17
Application:
1.Used in various household appliances such as disinfection cabinets,microwave ovens,air conditioners,air purifiers,etc. 2.Disinfection and sterilization of air and surface of objects in hospitals,schools,hotels,restaurants,homes and offices.
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 22
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 23
Certificate
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 24
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 25
uv lamp double side straight pipe ultraviolet uv led lights disinfection bulb sterilizing tube T5 10W 15W 20W 30W 40W 26
