ART 310 Rainwater Collection Tanks For Irrigation Water Storage

Categories Agricultural Water Storage Tanks
Brand Name: CEC TANKS
Model Number: W20161021023
Certification: ISO 9001:2008, AWWA D103 , OSHA , BSCI
Place of Origin: China
MOQ: 1set
Price: $5000~$20000 one set
Payment Terms: L/C, T/T
Supply Ability: 60 sets per month
Delivery Time: 0-60 days after deposit received
Packaging Details: PE poly-foam between each two steel plates ; wooden pallet and wooden box
Service life: ≥30 years
Permeability: Gas / liquid impermeable
Coating thickness: 0.25mm~0.40mm , two layer of coating internal and external
Steel grade: ART 310
Chemical Resistance: Excellent
Corrosion Integrity: Excellent
  • Product Details
  • Company Profile

ART 310 Rainwater Collection Tanks For Irrigation Water Storage

Rainwater collection tanks for Irrigation Water Storage and Agriculture Water Storage

The whole world is making every effort to collect and use rainwater for irrigation. This precious natural resource rainwater is lost due to surface runoff during storms, which has caused huge losses to the water management system that meets the growing world population. Only 2.3% of the available water on the earth can be used as fresh water. In order to prevent more fresh water from flowing into the ocean that turns into salt water, many specialized tank manufacturers around the world are designing rainwater storage systems.

The ability to collect rainwater for irrigation allows many small and medium-sized irrigation projects (such as plant nurseries) to fetch water during the dry summer months. For very large steel tanks, the size of the collection system ranges from 20 cubic meters to 20,000 cubic meters. The saved rainwater allows the owner to store enough water for gardening throughout the year.

Glass fused to steel tank is made up of glass fused steel with special sealant & self locking bolts, which are designed for optimum energy efficiency, durability and long lasting performance. They are commonly called “ Glass-Fused-to-Steel ” tank, also “ Glass-Fused-to-Steel Bolted Tank ”.Glass fused to steel irrigation water tanks provide irrigation water for farms, greenhouses, vineyards, and urban landscapes, as well as collecting rainwater in the summer for irrigation during water shortages in the fall, when household wells and local reservoirs are under strain. Water for irrigation is essential to sustain the growth of fruits, vegetables and grains, which needed to feed the world's population, especially in arid regions, and irrigation tanks are essential for irrigation water storage. The storage of water for irrigation is vital in areas that depend on agriculture for their economic development. High-quality irrigation water storage solution plays a key role in the development of the agricultural economy.

Glass Lined Steel Irrigation Water Tank Specifications

Coating colordark blue, dark green, white, and customized
A standard steel plate sizeeffective size 2400mm x 1200 m
Steel plates thickness3mm - 12mm, depends on the diameter & height
Coating thickness0.25mm - 0.4mm, two coatings internal and external
Acid and alkalinity proofstandard coating suits for PH3 - PH11, special coating suits for PH1 - PH14
Elasticsame as steel sheet, around 500KN/mm
Hardness6.0 Mohs
Service life>30 years
Spark test>1500 V
Permeabilitygas and liquid impermeable
Easy yo cleansmooth, glossy, inert, anti-adhesion
Corrosion resistance

excellent! Suitable for wastewater salt water, seawater, high sulfur crude oil,

salt fox, organic and inorganic compounds

Glass Lined Steel Tanks Advantage:

Short construction period, cost-effective tank solution
Superior corrosion resistance, service life is more than 30 years
Easy to install, no need for big installation equipment and/or very skilled labors
Tank volume can be easily expanded
It can be dismantled, removed and relocated
Elegant appearance, tank color can be customized

About Center Enamel Co., Ltd

Center Enamel Co., Ltd is not only the first Glass-Fused-to-Steel Tanks manufacturer and supplier in China, but also the most experienced Glass-Fused-to-Steel tanks manufacturer in all of Asia. Center Enamel Glass-Fused-to-Steel tanks engineering & design, product testing and quality system are in strict accordance with AWWA D103-09, OSHA, ISO/EN 28765, NSF61 and NFPA etc. international standards. CEC Glass-Fused-to-Steel tanks are widely used in drinking/potable water, industrial effluents, municipal sewage, bio-energy, landfill leachate, agriculture etc. applications. Until 2018, Center Enamel Glass-Fused-to-Steel tanks have been exported to more than 60 countries including USA, Australia, Canada, Malaysia, Indonesia, Russia, UAE, Panama, India and South Africa etc. The superior product quality and prompt service gain us worldwide recognition.
