400Nm Explosion proof valve actuator , on-off / modulating electric actuator

Categories Explosion Proof Electric Actuator
Brand Name: DCL
Model Number: DCL-Ex40
Certification: CE/ROHS/CSA/IP68/ATEX/IECEx/UL
Place of Origin: WUHAN,CHINA
MOQ: 1pc
Payment Terms: D/P, T/T, Western Union, MoneyGram
Supply Ability: 2000PCS/month
Delivery Time: 7 working days
Packaging Details: carton/pallet
Power: DC24V/AC110V/AC380V/AC220V
Standard Time/Torque: 30S/400Nm
Type: on-off, Modulating
Protection Class: IP67
Ambient Temperature: -20℃~+60℃
Motor power: 40W/70W/90W
Medium: Gas/Oil/Water/Other
Material of Seal Surface: Soft sealed
Rated Current: 0.29A~7.8A
Connection Form: Flange
  • Product Details
  • Company Profile

400Nm Explosion proof valve actuator , on-off / modulating electric actuator


  • Quarter turn operation with mechanical limits
  • Heavy duty motor with thermal overload protection
  • Rugged IP68/NEMA 4X aluminum alloy housing with powder coating
  • Explosion proof grade ExdIICT4 for Zone system and Group C, D T4 for Division system
  • Over torque protection is available
  • Anti-condensation heater is optional
  • Standard ISO5211 direct installation
  • Manual override with Allen wrench or handwheel
  • CSA certification


DCL explosion proof electric actuator can add over torque protection function inside cavity. Disc spring made in Germany with very long life span and very small deformation with frequently presses, are used to keep the over torque value set to be stable and no drift after long time operation.

Actuator can be used for over 90% explosive gas environment except for colliery. Motors and electronics are fire treated. The machining precise of the connection surface are strictly controlled and inspected from supplier to ensure the flameproof gap is small enough to block spark inside actuator. Aluminum housing is hard die casted with larger tonnage than common series electric actuator to be more dense and can suffer much larger explosive pressure.

CSA tests per UL and CSA standard, both for Zone system and Division system have passed and CSA certification is obtained in 2022.


Motor Power70W90W40W90W
Rated Current7.80A1.12A0.29A0.64A
Standard Time/Torque30S/400Nm
Optional Time/Torque15S/200Nm15S/200Nm 60S/400Nm
Turning Angle0~90° Adjustable
Available Control CircuitType of A,B,C,D,E,F,G,H,
Total Weight9.5kg
Insulating Resistance100MΩ/250VDC100MΩ/500VDC
Withstand Voltage ClassDC24V: 500VAC 1 minute,AC110V/AC220V: 1500VAC 1 minute,AC380V: 1800VAC 1 minute
Protection ClassIP67
Expiosive-proof gradeExⅡCT4Gb
Installation Angle360° at any angle
Electric Interface2-M20×1.5explosion-proof plug,clients should install corresponding explosion-proof cable connector when using according to the cable selected.
Ambient Temperature-20~+60℃
Optional FunctionOver-torque Protector/Heater
