Roadside Hydraulic Piling Machine 460T Piling Capacity No Air Pollution

Categories Hydraulic Piling Machine
Brand Name: T-WORKS
Model Number: ZYC460B-B1
Certification: ISO,CE,GOST
Place of Origin: CHINA
Price: Negotiable
Supply Ability: 10 UNIT PER MONTH
Delivery Time: 30-45 days
Packaging Details: Nude package by bulk vessel
Product Name: Hydraulic Piling Machine
Piling Stroke: 1.9m
Max Spun Pile Size: 600mm
Max Square Pile Size: 500mm
Piling Speed: 8.5m/min
Crane Lifting Capacity: 16ton
  • Product Details
  • Company Profile

Roadside Hydraulic Piling Machine 460T Piling Capacity No Air Pollution

ZYC Series Low Energy Consumption Hydraulic Piling Machine With 460T Piling Capacity Made By T-WORKS

1. Description:

We are able to produce nearly 40 ZYC models of Static pile drivers from 60 tons to 1200 tons at the customers'own choice,or make a new model according to the customers'requirement.

Each tonnage is classified into the following three models:

With the function of side piling and corner piling
Without the function of side piling and corner piling
With a connecting system for adding side piling and/or corner piling mechanism if necessary.

2. Applications:

  • No limitation on pile length. Suitable for construction in clay soil, soft soil and sand bed foundation, or in the Karst areas with low earth covering, or by riversides, or in coastal areas with deep bearing stratum.
  • No noise, No pollution during construction, especially suitable for operations in areas with noise control such as schools, social communities, and urban areas.
  • No vibrations. Suitable for vibration-control areas such as subways, overpass, dangerous buildings, precision instrument buildings and those nearby banks.

3. Specifications:

Rate piling pressure(KN)4600
Piling speed(m/min)Fast8.5
Piling stroke(m)1.9
Angle range(°)11
Rise stroke(m)1.1
Square pile(mm)Max500
Circle pile(mm)Max600
Side piling(mm)1250
Corner piling space(mm)2500
Lifting weight(t)12
Pile hanging length(m)14
Main dimension(m)Work length12.7
Work width7.1
Transpot height3.15
Total weight(t)460

4. Feature Advantage:

Our machine have the following features in contrast to others:

  • Counterweight Under the Crane:This design balances the counterweights on the machine , keep it from dangerous by the over stack
  • Unique design of attachable side piling structure, improves the capacity of side piling,meets the requirement of different site condition.
  • The holder of counterweight mean can be foldable,and convenient in loading .
  • Unique walking mechanisim with lubrication cup design could realize durable lubrication so as to extend serivice life of rail wheel.
